The Eltec HLB is a next-generation home lift that combines advanced technology with elegant design. Expertly engineered in Italy, this all-electric platform lift operates without hydraulic systems or a separate machine room, providing a quiet, energy-efficient solution perfect for both new builds and retrofit projects.
With its compact design and wide range of customisation options, the Eltec HLB integrates seamlessly into any architectural setting. Whether you’re improving accessibility in a private home or enhancing the style of a commercial property, this lift offers exceptional performance, flexibility, and contemporary sophistication.
| Regulations | European |
| Drive System | VVVF all-electric traction with counterweights |
| Country of Origin | Manufactured in Italy |
| Capacity | 250–400 kg (wheelchair accessible) |
| Maximum Travel | Up to 20 metres across 10 stops |
| Number of Stops | 10 |
| Maximum Speed | 0.15 m/s |
| Pit Depth | 180 mm |
| Headroom | 2550 mm |
| Motor Room | Not required; components housed within the shaft |
| Power Supply | Single-phase 230V, 10A |
| Certificate | Conforms to European Machinery Directive 2006/42/EC and EN81-41 standards |
Eltec HLB Home Lift – Engineered for Modern Living
Blending precision engineering with stylish adaptability, the Eltec HLB is a state-of-the-art, all-electric home lift designed for contemporary homes. Whether space is limited, energy efficiency is a priority, or a customised design is required, the HLB provides a smart, flexible solution.
✓ All-Electric Traction System
The Eltec HLB features a VVVF all-electric belt drive with counterweights, delivering smooth and virtually silent operation. Its energy-efficient design achieves an A-grade European rating, while the single-phase 230V, 10A power requirement keeps running costs low and environmentally friendly.
✓ Space-Saving Design
Perfect for compact spaces, the HLB requires just a 180mm pit and 2550mm headroom. With the motor and controller housed within the shaft, there is no need for a separate machine room, making installation simpler and more flexible.
✓ Fully Customisable
Personalise your lift to suit your interior style. Choose from a range of cabin sizes, door types, wall panels, flooring options, control panels, and lighting finishes, creating a lift that integrates seamlessly with your home.
✓ Flexible Shaft Options
Where a traditional lift shaft isn’t possible, the Eltec HLB offers modular solutions. The AU Shaft is ideal for indoor installations, while the TA Freestanding Shaft works indoors and outdoors. Both options are available in multiple finishes, including glass and aluminium, to complement any décor.
✓ Safety and Comfort First
With features such as emergency battery-powered lowering, intercom systems, and tactile controls, the HLB prioritises safety and ease of use. Its smooth ride and precise stopping make every journey comfortable and reliable.
Adapted and designed to the needs of each customer.
Pit 180mm, Minimum headroom 2520mm, Special versions with pit 140mm or headroom 2320mm, Maximum travel 20m
Reliable products tested to meet the most demanding standards.
Greater number of access points for maximum options
